AirMAX Lite AP GPS

Ubiquiti LAP-GPS UISP airMAX Lite AC AP 5GHz GPS Access Point

PRODUCT SPECIFICATIONS
Powerful and affordable 5 GHz sector access point. GPS synchronized units provide up to 450+ Mbps data throughput.

Introducing the airMAX® LiteAP™ AC, the latest high-performance access point with disruptive pricing from Ubiquiti. Featuring an ultra-lightweight form factor, the LiteAP AC was designed to be an affordable cost/performance solution for long-distance, wireless broadband bridging.

• Integrated 5 GHz antenna, 12+ km link range
• 450+ Mbps throughput
• 50+ client capacity
• Dedicated spectral analysis radio
• Integrated GPS sync
• Compatibilities
• Iversion LAP-GPS

Technical Description Mechanical

• Dimensions: 361 x 124.6 x 71.3 mm (14.2 x 4.9 x 2.8″)
• Weight: 752 g (1.66 lb)
• Wind survivability: 200 km/h (125 mph)
• Wind loading: 77 N at 200 km/h (17.3 lbf at 125 mph)

Hardware

• Networking interface: (1) GbE RJ45 port
• Power method: Passive PoE (pairs 4, 5+; 7, 8 return)
• Power supply: 24V, 0.3A Gigabit PoE adapter (Included)
• Supported voltage range: 20—26V DC
• Max. power consumption: 7.1W
• Max. TX power: 25 dBm
• Antenna gain: 17 dBi
• ESD/EMP protection: Air/contact ± 24kV
• Shock and vibrations: ETSI300-019-1.4
• Operating temperature: -40 to 70° C (-40 to 158° F)
• Operating humidity: 5 to 95% noncondensing
• Certifications: CE, FCC, IC
• Operating Frequency (MHz)

USA

• U-NII-1 5150 – 5250 MHz
• U-NII-3 5725 – 5850 MHz
• Management Radio (MHz)
• USA 2412 – 2462 MHz
