The new, updated revision of the CCR1009 is here. We've tried to incorporate all the customer feedback and best practices in CCR device manufacturing that we've learned over the past three years, since the first CCR1009 devices were released.
Important changes
No switching chip: The device now only has fully independent Ethernet ports, each with a direct connection to the CPU, overcoming the previous 1 Gbit shared limitation of switching chip ports and utilizing the full potential of the CPU's processing power on those ports.
Puerto combinado: una sola interfaz de software de 1 Gbit que tiene dos interfaces de hardware: una caja SFP y un puerto Gigabit Ethernet, lo que le permite usar cualquier tipo de conexión disponible para usted. También es posible cambiar entre ambas interfaces físicas en RouterOS. En caso de desconexión, el puerto combinado proporciona una función de conmutación por error de hardware.
100Mbps SFP Compatibility: This is our first device to support 100BASE-LX/100BASE-SX/100BASE-BX fiber modules, as well as standard 1.25G SFP modules.
More performance: Because the ports are now connected directly to the CPU, the new CCR1009 can achieve even greater performance.
Specs
| Details | |
|---|---|
| Details | CCR1009-7G-1C-1S+ |
| Architecture | TEJA |
| UPC | TLR4-00980 |
| CPU core count | 9 |
| CPU nominal frequency | 1,2 GHz |
| Dimensions | 443 x 175 x 44 mm |
| Router operating system license | 6 |
| Operating system | OS router |
| RAM size | 2 GB |
| Storage size | 128 MB |
| Storage type | NAND |
| MTBF | Approximately 200,000 hours at 25C |
| Tested ambient temperature | -20°C a 60°C |
| IPsec hardware acceleration | Yes |
